Ricoh P C301W - Front Cover Unit

4.Replacement and Adjustment
32
2. Open the front cover [A].
3. Release the hook and remove the left cover [A].
Top front screw: M3 x 8, others: M4 x 10
Front Cover Unit
1. Remove the rear cover. (Rear Cover)
2. Remove the operation panel. (Operation Panel)
3. Remove the right cover. (Right Cover)
4. Remove the transfer unit. (Paper Transfer Unit)
5. Remove the gear unit [A] ( x2).
