Ricoh P C301W - Paper Exit Sensor (S5)

4.Replacement and Adjustment
96
then remove it.
4. Remove the gear [A], bearing [B] and four exit guides [C].
Paper Exit Sensor (S5)
1. Remove the rear cover. (Rear Cover)
2. Remove the operation panel. (Operation Panel)
3. Remove the right cover. (Right Cover)
4. Remove the bracket [A].
