Ricoh P C301W - Pressure Roller

4.Replacement and Adjustment
82
10. Remove the fusing sleeve belt unit [A].
Pressure Roller
1. Remove the fusing unit. (Fusing Unit)
2. Remove the fusing upper cover. (Fusing Upper Cover)
3. Remove the fusing lower cover. (Fusing Lower Cover)
4. Remove the fusing sleeve belt unit. (Fusing Sleeve Belt Unit)
5. Remove the gear cover [A].
