Ricoh P C301W - Image Fusing; Fusing Unit

4.Replacement and Adjustment
73
Image Fusing
Make sure that the fusing unit is cool before you touch it. The fusing unit can be very hot.
Fusing Unit
1. Remove the left cover. (Left Cover)
2. Disconnect the two connectors.
3. Remove the fusing unit [A].
保存
保存
保存
保存
保存
After Replacing the Fusing Unit
After replacing the fusing unit, reset the PM counter.
1. Open the front cover.
2. Turn on the machine.
