Ricoh P C301W - Fusing Entrance Sensor (S2); Fusing Thermostat (TH1)

4.Replacement and Adjustment
75
2. Release the hook and slide the entrance guide plate [A] to the right to remove it.
3. Remove the lower cover [A].
Fusing Entrance Sensor (S2)
1. Remove the fusing unit. (Fusing Unit)
2. Remove the fusing lower cover. (Fusing Lower Cover)
3. Remove the fusing entrance sensor assembly, and then remove the fusing entrance sensor (S2)
[A].
Fusing Thermostat (TH1)
1. Remove the fusing unit. (Fusing Unit)
