3.Preventive Maintenance
24
Paper Transfer Quality Standards
Printer
Single Side:
Main Scan: 0 ± 2.0 mm
Sub Scan: 0 ± 1.5 mm
Duplex:
Main Scan: 0 ± 2.0 mm
Sub Scan: 0 ± 1.5 mm
Reference value when using the
bypass tray:
Main Scan: 0 ± 3.5 mm
Sub Scan: 0 ± 2.5 mm
Single Side:
± 1.0 mm/200 mm or less (B5 SEF or
more)
± 1.0 mm/100 mm or less (Less than B5
SEF)
Duplex:
± 1.0 mm/100 mm or less
Reference value when using the
bypass tray:
± 1.0 mm/50 mm
10 mm or less (In an office
environment)
20 mm or less (In other environments)
Main Scan: 0 ± 2.0 mm
Sub Scan: 0 ± 1.5 mm
Main Scan: ± 1.1% (± 2.2 mm/200 mm)
Sub Scan: ± 1.0% (± 2.8 mm/200 mm)
These standards are determined using the standard paper with the standard conditions. The values
may change depending on environmental conditions such as temperature, humidity, and paper type.
