Ricoh P C301W - HVPS (High Voltage Power Supply) (PCB3)

4.Replacement and Adjustment
113
7. Release all harnesses and FFC on the harness guide [A], and then remove the guide.
8. Remove the AC detection board (PCB5) [A].
HVPS (High Voltage Power Supply) (PCB3)
1. Remove the rear cover. (Rear Cover)
2. Remove the operation panel. (Operation Panel)
3. Remove the right cover. (Right Cover)
4. Remove the HVPS (PCB3) [A].
