Ricoh P C301W - Speaker (MF Model Only); Engine Board (EGB) (PCB1)

4.Replacement and Adjustment
104
Speaker (MF Model Only)
1. Remove the rear cover. (Rear Cover)
2. Remove the controller box cover [A].
3. Remove the speaker assembly [A].
4. Remove the speaker [A].
Engine Board (EGB) (PCB1)
1. Remove the rear cover. (Rear Cover)
2. Remove the controller box cover [A].
Printer model:
