Ricoh P C301W - Separation Pad

4.Replacement and Adjustment
94
7. Stand the machine up as shown below.
8. Slide the paper feed shaft [A] to the left side to remove the snap ring on both ends. ( × 2)
9. Release the hook and slide the paper feed roller [B] to remove it.
Separation Pad
1. Pull out the paper tray.
2. Push down the bottom plate [A].
