4.Replacement and Adjustment
74
3. Enter the SP mode.
4. Execute [Reset Fuser Unit].
Printer model: Engine Maintenance > Reset Fuser
MF model: Engine Service Setting > Reset Fuser Unit
Fusing Upper Cover
1. Remove the fusing unit. (Fusing Unit)
2. Remove the upper cover [A].
When removing the upper cover, raise up the pressure release levers on both sides.
Fusing Lower Cover
1. Remove the fusing unit. (Fusing Unit)
