4.Replacement and
Adjustment
103
Electrical Components
FCU (PCB8) (MF Model Only)
1.
Remove the rear cover
. (
Rear Cover
)
2.
Remove the controller box cover [A].
3.
Remove the USB dongle
[A] and the interface cover [B].
4.
Remove the FCU (PCB8) [A].
