4.Replacement and Adjustment
87
onto the bushing of the registration idle roller as shown below.
• If the paper dust has accumulated under the registration roller, clean with a soft damp
cloth, and then wipe with a dry cloth.
Paper Feed Clutch (CL1)
1. Remove the left cover. (Left Cover)
2. Remove the paper feed clutch (CL1) [A].
Paper Transport Motor (M3)
1. Remove the left cover. (Left Cover)
