Ricoh P C301W - Paper Feed and Transfer; Paper Transfer Unit

4.Replacement and Adjustment
84
Paper Feed and Transfer
Paper Transfer Unit
1. Open the front cover.
2. Pull the levers [A] on both sides to release the lock.
3. Hold the handles on both sides of the paper transfer unit [A] and lift it up and out.
保存
保存
保存
After Replacing the Paper Transfer Unit
After replacing the paper transfer unit or the paper transfer roller, reset the PM counter.
1. Open the front cover.
2. Turn on the machine.
3. Enter the SP mode.
4. Execute [Reset 2nd Transfer Unit].
Printer model: Engine Maintenance > Reset 2nd
MF model: Engine Service Setting > Reset Transfer Unit
