Ricoh P C301W - Cleaning Points

3.Preventive Maintenance
18
Cleaning Points
TM/P Sensor
1. Open the upper cover.
2. Remove the rearmost print cartridge, and then slide the TM/P sensor lever once to the left.
Exposure Glass (Only MF Model)
1. Open the ADF unit.
2. Clean the parts indicated by arrows with a soft damp cloth, and then wipe the same parts with a dry
cloth to remove any remaining moisture.
ADF Exposure Glass (Only MF Model)
1. Open the ADF unit.
2. Clean the parts indicated by arrows with a soft damp cloth, and then wipe the same parts with a dry
