Ricoh P C301W - Test Pattern

5.System Maintenance
165
Menu
Des
[Off / On]
Sleep Mode Setting
[Off / On]
Test Pattern
Menu
Description
Test Pattern
Pattern Selection
Selects the test pattern.
[0 to 23 / 0 / 1/step]
• 0: None
• 1: Vertical line (1 dot)
• 2: Horizontal line (1 dot)
• 3: Vertical line (2 dots)
• 4: Horizontal line (2 dots)
• 5: Grid vertical line
• 6: Grid horizontal line
• 7: Grid pattern (20 mm)
• 8: Argyle pattern Small
• 9: Argyle pattern (20 mm)
• 10: Independent pattern (1 dot)
• 11: Independent pattern (2 dots)
• 12: Independent pattern (4 dots)
• 13: Full dot pattern
• 14: Band
• 15: Trimming frame (4 dots)
• 16: Trimming frame (2 dots)
• 17: Trimming frame (1 dots)
• 18 to 23: Not used
Color Selection
Selects the printing color.
[1 (All color) / 2 (Ma) / 3 (Ye) / 4 (Cy)]
Density: All
Sets the density.
[0 (Density 0%) to 15 (Density 100%) / 15 / 1/step]
Print Side Selection
Sets the printing side.
[0 (Single) / 1 (Duplex)]
Paper Size Selection
Selects the paper size.
[0 (LGT) / 1 (A4T) / 2 (B5T) / 3 (A5T)]
1 Sheet Printing
Prints out a test pattern.
