Ricoh P C301W - Fusing NC Sensor (S1); Pressure Roller Thermistor (End) (TH4)

4.Replacement and Adjustment
76
2. Remove the fusing upper cover. (Fusing Upper Cover)
3. Remove the fusing thermostat (TH1) [A].
Fusing NC Sensor (S1)
1. Remove the fusing unit. (Fusing Unit)
2. Remove the fusing upper cover. (Fusing Upper Cover)
3. Remove the fusing NC sensor (S1) [A].
Pressure Roller Thermistor (End) (TH4)
1. Remove the fusing unit. (Fusing Unit)
2. Remove the fusing upper cover. (Fusing Upper Cover)
3. Remove the fusing lower cover. (Fusing Lower Cover)
