4.Replacement and Adjustment
77
4. Remove the two springs on the fusing exit guide plate [A].
5. Open the fusing exit guide plate [A] to remove it.
6. Remove the stay [A].
7. Remove the pressure roller thermistor assembly, and then remove the pressure roller thermistor
