Ricoh P C301W Field Service Manual

5.System Maintenance
135
Menu
Description
Previous 2:Pages
Displays page count (sheets) for the 2nd
fusing unit before current unit.
Previous
2:Distance
Displays distance count (mm) for the 2nd
fusing unit before current unit.
Previous 3:Pages
Displays page count (sheets) for the 3rd
fusing unit before current unit.
Previous
3:Distance
Displays distance count (mm) for the 3rd
fusing unit before current unit.
Previous 4:Pages
Displays page count (sheets) for the 4th
fusing unit before current unit.
Previous
4:Distance
Displays distance count (mm) for the 4th
fusing unit before current unit.
Previous 5:Pages
Displays page count (sheets) for the 5th
fusing unit before current unit.
Previous
5:Distance
Displays distance count (mm) for the 5th
fusing unit before current unit.
Frequency
Displays the detection frequency.
[50 to 60 / 60 / 1Hz/step]
Voltage Detection
Heater ON
Displays the detection voltage when the
fusing lamp is on.
Max
Displays max. value of detected voltage.
Min
Displays min. value of detected voltage.
Last
Displays the value of most recently
detected voltage.
SC
Displays the detected voltage at time of
SC occurrence.
Threshold Voltage
Displays detected voltage at STOP.
Inrush Control
Sets the Inrush Control mode. When
using with an external power supply
instead of a commercial power supply,
set to "On".
[Off/ On]
Flicker Control
Sets the Flicker Control mode.
[Off / On]
I/O Check
INPUT Check
Fusing:New Unit
Detect.
Displays the fusing unit status.
0: New unit, 1: Old unit
Registration
Displays the registration sensor status.

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
