Ricoh P C301W Field Service Manual

5.System Maintenance
142
Menu
Description
[Disable/ Enable]
Comm. Test Call
Sets the communication test call.
[Disable/ Enable]
Machine Info Notice
Sets the machine information notice.
[Disable/ Enable]
Supply Auto
Ordering Call
Sets the supply auto ordering call.
[Disable/ Enable]
Machine No.
Setting
ID2 Code Display
Displays the ID2 code (ASCII 17digits).
Remote
Service
CE call
Performs the CE Call at the start or end of the service. [OK
/Back]
Function Flag
Enables or disables the remote service function.
[Disable/ Enable]
Communication Test
Executes the communication test. [OK /Back]
RCG Reg. State
Displays the RCG registration status.
[0 to 2 / 0 / 1/step]
GW URL
Displays the URL for RCG center.
Polling Interval
Sets the polling interval.
[0 to 4294967295 / 60 / 1 sec/step]
HTTP Con Timeout
Specifies the connect timeout interval when calling the RCG.
[1 to 90 / 30 / 1 sec/step]
HTTP Sen Timeout
Specifies the send timeout interval when calling the RCG.
[0 to 100 / 30 / 1 sec/step]
HTTP Rec Timeout
Specifies the receive timeout interval when calling the RCG.
[0 to 100 / 30 / 1 sec/step]
HTTP Retry Interval
If the HTTP connection fails, specify the interval at which the
connection will be retried again.[0 to 65535 / 3 / 1 sec/step]
HTTP Retry #
If the HTTP connection fails, specify the number of times to
retry the connection.
[0 to 255 / 3 / 3 counts/step]
HTTP Con Delay
Specifies the connection request sending delay.
[0 to 255 / 5 / 1 sec/step]
Max Multipart
Specifies the maximum number of multipart.
[0 to 10 / 10 / 1/step]
Rescue G/W URL
Displays the rescue URL.
Per Notice Mode
Sets the periodic notification mode.
[0 to 5 / 0 / 1/step]

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
