Ricoh P C301W Field Service Manual

5.System Maintenance
161
Menu
Description
[0Km/ 1.8Km/ 3.6Km/ 7.2Km]
Protocol
Definition
Training Retries
This sets the number of training retries to be repeated
before automatic fallback.
[1 Time / 2 Times / 3 Times / 4 Times]
Encoding
Sets the compression method for Tx/Rx.
[MMR+MR+MH / MR+MH / MH]
Protocol
Definition
Timer
T0 Timer
Timeout for response from the called station in automatic
sending mode
[35 Sec/ 45 Sec/ 55 Sec/ 60 Sec/ 90 Sec/ 140 Sec]
T1 Timer
Set the time length for the T1 timer.
[40 Sec / 50 Sec]
T4 Timer
Set the time length for the T4 timer.
[3 Sec / 4.5 Sec]
RX Settings
Silence Detection
Silence (No tone) detection time (Rx mode Only)
After the line is connected via the external telephone, the
machine can detect silence (no tone) for the time length
specified by this setting.
[30 sec (Default)]
CNG Tone Detection
Time
CNG tone detection time
After the line is connected via the external telephone, the
machine can detect a CNG signal for the time length
specified by this setting.
[5 Sec / 10 Sec]
CNG Cycles
Number of CNG cycles to be detected
[1.5 Cycle / 2.0 Cycle]
Tone Sound
Monitoring
Determines the period when tones from the line are
monitored.
[No Monitoring / Up To Phase B / All TX Phases]
Stop/Clear key
Pressing the Stop/Clear key can stop the current receiving
operation. Received data is lost.
[No Functional / Functional]
Off-Hook Level
Do not change this setting (DFU).
[10V / 15V / 20V / 25V]
Off-Hook Detection
Period
Sets the Off-Hook detection period.
[200 ms / 800 ms]
Number for Remote
Switch
[0 to 9 / 2 / 1step]

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
