Ricoh P C301W Field Service Manual

6.Troubleshooting
203
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
1. Replace the fusing thermopile anti-condensation fan (FAN4).
2. Re-connect the connector of the fusing thermopile anti-condensation fan
(FAN4).
3. Replace the fusing thermopile anti-condensation fan (FAN4) harness.
4. Replace the EGB (PCB1).
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
SC541-
00
A
Fusing thermopile (TH2) disconnect error
After turning the fusing lamp on, the fusing thermopile has detected the AD value
of 0x004 (about -50 °C) or below continuously for 0.2 seconds.
• Fusing thermopile (TH2) disconnected
• Harness connector lose, broken, or defective
Enter the SP mode and execute fuser SC reset. Then turn the machine OFF and
ON.
If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling
the power after each step.
1. Re-connect the connector of the fusing thermopile (TH2).
2. Replace the fusing thermopile (TH2).
3. Replace the fusing thermopile (TH2) harness.
4. Replace the EGB (PCB1) or/and the PSU (PCB4).
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
SC542-
02
A
No reload temperature of the fusing thermopile (TH2)
After turning the fusing lamp on, the fusing thermopile has failed to reach the
reload temperature (96 °C) continuously for 8.6 seconds.
SC542-
03
A
No reload temperature of the fusing thermopile (TH2)
After reaching the reload temperature, the fusing thermopile has failed to reach the
reload temperature (96 °C) continuously for 19.8 seconds.
• Thermopile lens dirt
• Power supply voltage low
• Overheating protection device triggered (blown fusing thermostat)
Enter the SP mode and execute fuser SC reset. Then turn the machine OFF and
ON.
If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling
the power after each step.
1. Check the input power source and reconnect the cable to the outlet.
2. Replace the fusing thermopile (TH2).

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
