Ricoh P C301W Field Service Manual

6.Troubleshooting
211
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
• Thermistor is deformed or not in contact
• Power supply voltage low
• Overheating protection device triggered (blown fusing thermostat)
• Fusing drive non-rotation
Enter the SP mode and execute fuser SC reset. Then turn the machine OFF and
ON.
If the SC occurs again, do the following steps. Check if the SC reoccurs by cycling
the power after each step.
1. Check the input power source and reconnect the cable to the outlet.
2. Replace the pressure roller thermistor (center) (TH3).
3. Replace the fusing thermostat (TH1).
4. Replace the fusing unit.
5. Replace the EGB (PCB1) or/and the PSU (PCB4).
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
SC562-
12
D
No reload temperature of the pressure roller thermistor (center) (TH3): Low voltage
After turning the fusing lamp ON, the pressure roller thermistor (center) has failed
to reach -40 °C continuously for 30 seconds. AND the power supply voltage is
lower than specified voltage.
• Thermistor is deformed or not in contact
• Power supply voltage low
• Overheating protection device triggered (blown fusing thermostat)
• Fusing drive non-rotation
Check if the SC occurs by turning the power OFF then ON. If the SC occurs again,
do the following steps. Check if the SC reoccurs by cycling the power after each
step.
1. Check the input power source and reconnect the cable to the outlet.
2. Replace the pressure roller thermistor (center) (TH3).
3. Replace the fusing thermostat (TH1).
4. Replace the fusing unit.
5. Replace the EGB (PCB1) or/and the PSU (PCB4).
6. If the problem is low voltage, ask the client to connect the machine directly to
a rated power source and to refrain from using extension cords.
SC No.
Type
Error Name/Error Condition/Major Cause/Solution
SC563-
00
A
High-temperature software error (pressure roller thermistor (center) (TH3))
After turning the fusing relay ON, the pressure roller thermistor (center) has
detected over 248 °C continuously for 1 second.
