Ricoh P C301W Field Service Manual

6.Troubleshooting
227
Transport path
Length (mm)
Note
Paper feed roller - Friction pad nip
9.5
Registration sensor ON - Registration sensor OFF
8.2
Registration sensor ON - Registration roller
14.3
Registration roller - Paper transfer roller
38.1
Paper transfer roller - Fusing entrance sensor ON
60.7
Fusing entrance sensor ON - Fusing entrance sensor OFF
3.0
Paper transfer roller - Fusing sleeve belt
97.3
Fusing sleeve belt - Paper exit sensor ON
59.2
Paper exit sensor ON - Paper exit sensor OFF
18.4
Paper exit sensor ON - Paper exit roller
47.0
Paper exit roller - Duplex roller
200.0
Duplex roller - Registration sensor ON
174.6
Registration sensor ON - Registration roller
17.0
Duplex feed
Exposure - Image transfer roller (Bk)
37.2
Image transfer roller (Bk) - TM/P sensor
219.61
TM/P sensor - Paper transfer roller
330.08
Image transfer roller (Bk) - Paper transfer roller
549.69
Paper Feed Unit TK1220
Transport path
Length (mm)
Note
Paper feed roller - Paper transport roller
47.1
Paper transport sensor - Paper transport roller
5.3
Paper transport roller - Registration sensor ON
86.0
Registration sensor ON - Registration roller
17.0
Paper transport roller - Duplex feed junction
61.0

Ricoh P C301W Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	9.4 s
Time to first page (color, normal)	9.8 s
Print speed (black, normal quality, A4/US Letter)	25 ppm
Internal memory	256 MB
Built-in processor	-
Sound pressure level (printing)	- dB
Cables included	AC
Included cartridge capacity (black)	1000 pages
USB 2.0 ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Duplex media weight	60 - 90 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	751 sheets
Auto document feeder (ADF) input capacity	1 sheets
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra
Server operating systems supported	Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (printing)	1300 W
Energy Star Typical Electricity Consumption (TEC)	0.3 kWh/week
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	65000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c, PCL 6, PostScript 3
Product color	Black, White
Market positioning	Home & office
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	450 mm
Width	400 mm
Height	334 mm
Weight	25000 g
