驱动器设置
—80—
Wiring – Sick5V (HIPERFACE protocol and sine signal)
Table 4-29 Feedback wiring – Sick5V (HIPERFACE protocol and sine signal)
Pin
Numbe
r
Twisted
pair
cables
User motor pin
number
Signal declarations
1
Twisted
pair
cables
Serial data+
14
Serial data-
9
Twisted
pair
cables
Sine encoder sine+
22
Sine encoder sine-
10
Twisted
pair
cables
Sine encoder cosine+
23
Sine encoder cosine-
12
Twisted
pair
cables
Motor temperature sensor
25
Motor temperature sensor
11
+5V DC voltage
24
0V DC voltage
26
Shielding
Wiring – Sick8V (HIPERFACE protocol and sine signal)
Table 4-30 Feedback wiring – Sick8V (HIPERFACE protocol and sine signal)
Pin
Numb
er
Twisted pair
cables
User motor pin
number
Signal declarations
1
Twisted pair
cables
Serial data+
14
Serial data-
9
Twisted pair
cables
Sine encoder sine+
22
Sine encoder sine-
10
Twisted pair
cables
Sine encoder cosine+
23
Sine encoder cosine-
12
Twisted pair
cables
Motor temperature sensor
25
Motor temperature sensor
18
+8V DC voltage
24
0V DC voltage
26
Shielding
Note:
If the motor does not support a temperature sensor, do not connect pins
12 and 25.
Note:
If the motor does not support a temperature sensor, do not connect
pins 12 and 25.
