Chapter 8 Operating Instructions
CLV 480 Bar Code Scanner
8-10 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Troubleshooting
8.5.2 Malfunctions in Reading mode: reading trigger errors
¾ Check whether the "Device Ready" LED lights up.
If the LED does not light, see Table 8-5, Page 8-9.
CLV in stand-alone configuration
Malfunction Possible cause Remedy
1. Trigger mode:
Sensor input (external sensor).
The CLV cannot be clocked:
the "Sensor" LED does not light up
the red scan line does not appear
Sensor not connected or connected to
incorrect switching input.
If sensor supplied by CLV: sensor not
connected to ground potential.
Incorrect reading pulse source para-
meterized in the CLV.
Polarity of switching input inverted
Incorrect debouncing of the switching
input parameterized in the CLV.
Photoelectric switch not aligned with the
reflector (photoelectric proximity switch/
inductive sensor not dampened).
The object does not pass the reading
pulse sensor for trigger start with the
conveyor running.
Connect sensor to "Sensor" switching
input.
Check sensor wiring (see Fig. 5-4,
Page 5-17).
Measure output signal on sensor.
Insert jumper between pin 5 and pin 15
(AMV/S 60: "GND_SensGND" jumper)
In the "CLV-Setup" program: choose the
DEVICE CONFIGURATION tab, READING TRIG-
GER SOURCE section: Sensor input select-
ed? (active high: reading pulse starts
when power applied, active low: reading
pulse starts when power removed)
See above.
In the "CLV-Setup" program: choose the
DEVICE CONFIGURATION tab, click the
READING TRIGGER PARAMETERS button,
DEBOUNCING SENSOR section:
Time controlled: selected value too high?
Track controlled: incremental encoder
connected to "IN 4" switching input?
Align sensor.
Check functioning
Install reading pulse sensor in front of the
CLV in conveying direction. See also
Chapter 4.4.2 Mounting the external rea-
ding pulse sensor, Page 4-10 .
Table 8-6: Troubleshooting: reading trigger errors in Reading mode (CLV in stand-alone configuration)
