Electrical installation
The procedures for connecting and configuring the AMV/S Connection Modules are
described in the following documentation:
• Operating Instructions for the "AMV/S 60 Connection Module" (no. 8 008 296)
• Operating Instructions for the "AMV 30-071 Connection Module" (no. 8 008 648)
• Operating Instructions for the "AMV 100/200 Connection Module" (no. 8 008 879)
5.2.4 Connections/cables for the Bus Connection Modules
BMV 10 and BMS 20
The BMV 10 Bus Connection Module (depending on the model) is used to connect a CLV
to the Profibus-DP, DeviceNet, or to the Ethernet for use in industrial applications.
The BMS 20 Bus Connection Module enables the CLV to be integrated in the Interbus-S.
Connecting the CLV to the BMV 10/BMS 20
BMV 10: two cables no. 2 020 302 are required.
BMS 20: the cables no. 2 020 265 and no. 2 020 264 are required.
Alternatively, via external parameter memory no. 2 020 307 (see Chapter 5.2.5 Connec-
tions/cables for the external parameter memory (connection to AMV/S or BMV 10/
BMS 20).
a) CLV without heater:
Connection modules: BMV 10 and BMS 20.
The cables no. 2 020 302 can be extended to 10 m (32.8 ft) for CLVs without a heater
(host and terminal interface: RS
232!).
b) CLV with heater:
Connection module: BMV 10.
The BMV 10 may only be used if it is mounted outside the refrigeration area (temperature
range 0 to +40
°C (32 to 104 °F).
The cables no. 2 020 302 must not be extended. If longer cables are required, the entire
power supply system (Pin 1/Pin 5) must be connected with a wire cross-section of at least
0.75 mm
2
(approx. 20 AWG) at a maximum of 10 m (32.8 ft).
Recommendation Use the cable no. 2 021 298 (with two connector covers, length 3 m (9.84 ft)).
The BMS 20 is not suitable for powering CLVs with heater!
The procedures for connecting and configuring the Bus Connection Modules are described
in the following documentation:
• Operating Instructions for the "BMV/BMH 10 for Profibus DP Bus Connection Module"
(no. 8 008 825)
• Operating Instructions for the "BMV/BMH 10 for DeviceNet Connection Module"
(no. 8 008 972)
• Operating Instructions for the "BMV/BMH 10 for Ethernet Connection Module"
(no. 8 009 398)
• Technical Information for the "BMS 20 for Interbus-S Bus Connection Module"
(no. 8 007 546)
