Operating Instructions Chapter 6
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 6-9
Operation
6.4.3 Guide to parameterization menu
Overview of parameterization steps
• a) Parameterizing focus position switchover
• b) Parameterizing optical read properties of the scanner
• c) Optional: Configuring oscillating mirror functions
• d) Parameterizing a read pulse timing
• e) Parameterizing laser timeout
• f) Parameterizing the decoder’s evaluation properties
• g) Parameterizing the output properties (data, result status)
• h) Parameterizing the terminal interface function (auxiliary interface)
• i) Parameterizing the source of the parameter set for starting up (only with external
parameter memory)
When the CLV is switched on for the first time, it is started with the factory default settings.
The following parameters must then be set:
Note The minimum and maximum values for the active evaluation range of the scan line (MIN. AND
M
AX. CODE POSITION) can be checked in the SHOW CP-LIMITS mode.
See Chapter 6.5.4 Show CP-limits, Page 6-30.
a) Parameterizing focus position switchover
Action Settings in CLV-Setup
1. Activate focus control func-
tion (choose trigger source)
Ö READING CONFIGURATION tab
Ö FOCUS CONTROL section
– Inputs/Serial or
– Timer ÖTIMER or
– Static/No Trigger
Oscillating mirror:
– additional: Oscillating mirror extrema
2. Set up distance
configurations
Ö READING CONFIGURATION tab
Ö DISTANCE CONFIGURATION button
Ö DISTANCE CONFIGURATION tab
– Focus Position
– Minimum Code Position CP
– Maximum Code Position CP
Oscillating mirror:
– additional: Oscillating mirror amplitude CW
Ö ASSIGNMENT TABLE tab
– Index
– No. of valid configurations
3. Choose focus switchover
point (referred to reading
pulse)
Ö READING CONFIGURATION tab
Ö FOCUS CONTROL section
Ö INPUTS/SERIAL
– Immediate or Synchronous (default) or
– Latched (special application)
4. In INPUTS/SERIAL trigger
source: choose function for
"IN 3" and "IN 4" switching
inputs
Ö READING DEVICE CONFIGURATION tab
Ö ASSIGNMENT OF INPUTS section
Ö IN 3
– Focus Control
Ö IN 4
– Focus Control
Table 6-4: Guide: Parameterizing focus position switchover
