Operating Instructions Chapter 10
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 10-1
Appendix
10 Appendix
10.1 Overview
The appendix contains the following additional information:
• Specification diagrams
– Line scanner
– Line scanner with oscillating mirror
• Installation and operating instructions for the external parameter memory
• Optional heating (temperature graph/ switching on function)
• System messages
• Installation and operating instructions for the PC-based "CLV-Setup" program
• Configuring a CLV using command strings
• Parameter value calculations for configuring the CLV
• Tables
• Special applications and procedures
• Instructions for replacing a CLV (copying the parameter set)
• Accessories
• Dimensioned drawings of the accessories
• Notes on supplementary documentation
• Glossary
• Copy of the EC-Declaration of Conformity
• Index
• Scannable sample bar codes
10.2 Specification diagrams
10.2.1 Reading conditions for all diagrams
Note The min. and max. reading distances from the CLV are measured radially.
Test code Code 128
Print ratio > 90 %
Tilt ±30°/±45°
Ambient light < 2,000 lx
Good Read rate > 75 %
Table 10-1: Reading conditions for specification diagrams
