Operating Instructions Chapter 5
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 5-1
Electrical installation
5 Electrical installation
5.1 Installation sequence
• Connect the CLV to a SICK Connection Module from the series AMV/S, BMV/BMH 10
or BMS
20, or using a customer-specific wiring configuration
• Connect the data and function interfaces of the CLV in the module
• Connect the PC to the Connection Module (at the terminal interface on the CLV)
• Connect the power supply to the Connection Module
5.1.1 SICK Connection Modules (overview)
CLV Type Temperatur
range
Connection
module
Purpose see
chapter
CLV without heater 0 to +40 °C
(+32 to +104 °F)
AMV 60 – Connecting one CLV
– Operating voltage 18 to 30 V DC
– Enclosure rating IP 30, max. IP 54
5.2.3
AMS 60 – Connecting one CLV
– Operating voltage 230 V AC (115 V)/24 V DC
– Enclosure rating IP 30, max. IP 54
5.2.3
AMV 100 – Connecting one CLV
– Operating voltage 18 to 30 V DC
– Enclosure rating IP 52,
with connector cover max. IP 65
5.2.3
BMV/BMH 10
Bus Connection
Module
– Connecting one CLV to the Profibus-DP, DeviceNet
or Ethernet
– Operating voltage 20 to 30 V DC
– Enclosure rating IP 52,
with connector cover max. IP 65
5.2.4
BMS 20
Interbus-S
– Connecting one CLV to the Interbus-S
– Operating voltage 24 V DC
– Enclosure rating max. IP 54
5.2.4
AMV 30-071 – Connecting two CLVs
– Operating voltage 18 to 30 V DC
– Enclosure rating IP 30, max. IP 54
5.2.3
AMV 200 – Connecting two CLVs
– Operating voltage 18 to 30 V DC
– Enclosure rating IP 52,
with connector cover max. IP 65
5.2.3
CLV with heater
– Line scanner
– Line scanner
with oscillating
mirror
AMV 100 – Connecting one CLV 5.2.5
–35 to +35 °C – Operating voltage 24 V DC +20%/–10%
–35 to +35 °C
(–31 to +95 °F)
– Enclosure rating IP 52,
with connector cover max. IP 65
AMV 200 – Connecting two CLVs
– Operating voltage 24 V DC +20%/–10%
– Enclosure rating IP 52,
with connector cover max. IP 65
5.2.3
Table 5-1: Connection Modules for the CLV
