Chapter 10 Operating Instructions
CLV 480 Bar Code Scanner
10-52 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Appendix
10.12 Accessories
10.12.1 Mounting accessories
10.12.2 Connection modules
Order No. Description Figure
2 016 110 Quick clamping device, complete with securing material Fig. 10-38, Page 10-57
2 013 824 Angle bracket, single, with 2 screws M6 x 10 mm (0.39 in), self-locking Fig. 10-36, Page 10-57
2 018 435 Articulated bracket (two angle brackets 2 013 824), with 2 screws M6 x 10 mm (0.39 in),
self-locking
Fig. 10-37, Page 10-57
Table 10-11: Accessories: mounting accessories
Order No. Type Description
1 017 134 AMV 60-011 Connection Module for one CLV 480 without heater, with 1 x 15-pin D Sub HD device socket/plug,
terminal strips (signal distributor) for connecting the data and function interfaces, internal 9-pin D
Sub "Service" plug, strain-relief clamps, polycarbonate housing, enclosure rating IP 30 (max. IP 54),
operating voltage 18 to 30 V DC, operating temperature 0 to +40 °C (+
32 to +104 °F)
1 017 139 AMS 60-013 As AMV 60-011, with integrated power pack: 230 V AC 50 Hz/24V DC
1 017 140 AMS 60-012 As AMV 60-011, with integrated power pack: 115 V AC, 50 to 60 Hz/24V DC
1 017 387 AMS 60-023 As AMS 60-013, with 2-row LCD
1 017 391 AMV 30-071 Connection Module with two CLV 480 without heater, with 2 x 15-pin D Sub HD device socket/plug,
terminal strips (signal distributor) for connecting the data and function interfaces, two 9-pin D Sub
"Service" plugs, strain-relief clamps, polycarbonate housing, enclosure rating IP
30 (max. IP 54),
operating voltage 18 to 30 V DC, operating temperature 0 to +40 °C (+32 to +104 °F)
1 019 592 AMV 71-081 Connection module for CLV 480 without heater, with 1 x 15-pin D Sub HD device socket/plug,
spring terminal strips (signal distributors) for connecting the data and function interfaces, internal 9-
pin D-Sub "Service" plug, plastic cable glands, polycarbonate housing, enclosure rating max. IP 30.
With address function for network operation, operating voltage 10 to 30 V DC, operating tempera-
ture 0 to +40 °C (+32 to +104 °F)
6 021 105 AMV 100-011 Universal Connection Module for one CLV 480 with/without heater, with 1 x 15-pin D Sub HD
device socket/plug, terminal strips (signal distributor) for connecting the data and function inter-
faces, internal 9-pin D Sub "Service" plug, strain-relief clamps, cast aluminum housing, enclosure
rating IP 54 (max. IP 65 with connector cover), operating voltage 18 to 30 V DC, operating temper-
ature 0 to +40 °C (+32 to +104 °F)
6 021 106 AMV 200-011 As AMV 100, but for two CLV 480s with/without heater
6 007 655 – Power cable for AMS 60, 3-wire, length 2 m (6.56 ft), with 3-pin connector (grounding) and one
open end (stripped)
Table 10-12: Accessories: connection modules
