SICK CLV 480 - Fig. 10-21: CLV 480-1010-1011 (Line Scanner with Oscillating Mirror): Deflection Range as a Function of Radial Reading Distance, Deflection Angle and Resolution

Operating Instructions Chapter 10
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 10-21
Appendix
Fig. 10-21: CLV 480-1010/-1011 (line scanner with oscillating mirror): deflection range as a function of radial reading distance,
deflection angle and resolution
Line scanner with oscillating mirror (side reading window): CLV 480-1010/-1011
Reading conditions:
See Table 10-1, Page 10-1
R
e
s
o
l
ut
i
o
n:
Radial reading distance
Deflection range
All dimensions in mm (in)
