Operating Instructions Chapter 6
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 6-15
Operation
Action Settings in CLV-Setup
Parameterize reading trigger:
one external sensor
– or –
Ö DEVICE CONFIGURATION tab
Start:
Ö READING TRIGGER SOURCE section
– Sensor Input (Active High) or
– Sensor Input (Active Low)
Ö READING TRIGGER PARAMETERS button
Ö DEBOUNCING SENSOR section
– Standard or
– Fast or
– Time controlled: value or
– Track contolled: value
(with connected increment sensor)
Ö FIRST TRIGGER SENSOR section
– Edge or
– Level
Stop:
Ö END OF READING INTERVAL section
– generated by Trigger Source or
– Timer: Timeout (referred to beginning of reading interval)
Output of reading result referred to beginning of reading
interval:
Ö DEVICE CONFIGURATION tab
Ö OUTPUT ON GOOD READ section
– End of reading gate or
– Immediate or
– End of Label
Ö Using End of label: READING TRIGGER PARAMETERS button
Ö END OF LABEL/FREE-RUNNING section
– Timeout
Note:
Connect the external sensor to "Sensor“ switching input!
Table 6-7: Guide: Parameterizing the reading trigger for start/stop mode in stand-alone
configuration
