Chapter 6 Operating Instructions
CLV 480 Bar Code Scanner
6-16 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Operation
Parameterize reading trigger:
two external sensors
– or –
Ö DEVICE CONFIGURATION tab
Start (sensor 1):
Ö READING TRIGGER SOURCE section
– Sensor Input (Active High) or
– Sensor Input (Active Low)
Ö READING TRIGGER PARAMETERS button
Ö DEBOUNCING SENSOR section (also for sensor 2 on "IN 4")
– Standard or
– Fast or
– Time controlled: value
Ö FIRST TRIGGER SENSOR section
– Edge or
– Level
Stop (sensor 2):
Ö END OF READING INTERVAL section
– generated by IN 4
Ö DEVICE CONFIGURATION tab
Ö ASSIGNMENT OF INPUTS section
Ö IN 4
– Reading Trigger Stop (Active High) or
– Reading Trigger Stop (Active Low)
Output of reading result referred to beginning of reading
interval:
Ö OUTPUT ON GOOD READ section
– End of reading gate or
– Immediate or
– End of Label
Ö Using End of label: READING TRIGGER PARAMETERS button
Ö END OF LABEL/FREE-RUNNING section
– Timeout
Note:
Connect sensor 1 to "Sensor“ switching input and sensor 2 to
"IN 4“ switching input!
Action Settings in CLV-Setup
Table 6-7: Guide: Parameterizing the reading trigger for start/stop mode in stand-alone
configuration (contd.)
