Operating Instructions Chapter 3
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 3-1
Product description
3 Product description
3.1 Design
3.1.1 Scope of delivery
The CLV is supplied with the following in the packing:
• An information sheet (notes on device) with terminal diagram and Quick Start instruc-
tions
• An additional set of Class 2 laser warning labels (self-adhesive) in German/US English
and French/US English
Depending on the number of devices ordered, one or more of the following:
• CD-ROM (no. 2 029 112) with
– "CLV-Setup" program for Windows
TM
and the "CLV-Setup Help" online help system
(HTML files)
– "CLV-Connect" PC software (HTML files showing terminal diagrams)
– CLV 480 Operating Instructions in English and German as PDF edition as well as
additional publications (connections module, other SICK bar code scanners)
– freely available "Acrobat Reader" PC software for reading PDF files
Note The latest versions of all the current publications/programs on the CD-ROM can also be
downloaded from
www.sick.com.
Depending on the number of copies ordered, the delivery includes (optional):
• CLV 480 Operating Instructions in English and/or German (printed edition)
Chapter 10.12 Accessories, Page 10-52 contains an overview of the available mounting
accessories, (bus) connection modules, external parameter memories, cables, connectors,
incremental encoder, and network controller as well as sensors for generating the reading
pulse.
3.1.2 Variants
The CLV is currently available in the following variants:
3.1.3 System requirements for stand-alone configuration
CLV without heater The following are required to start up and operate the CLV 480 without heater:
1. A SICK Connection Module to provide the power supply and connect the data and
function interfaces. Available types:
–For connecting one CLV:
AMV 60-011 (no. 1 017 134) for 18 to 30 V DC, enclosure rating max. IP 54
AMS 60-013 (no. 1 017 139) for 230 V AC 50 Hz/24 V DC,
enclosure rating max. IP 54
Type (red light) Part. no. Scanning method Reading window Heater
CLV 480-0010 1 024 065 Line scanner End No
CLV 480-1010 1 024 066 Line scanner with oscillating mirror Side Yo
CLV 480-0011 1 024 067 Line scanner End Yes
CLV 480-1011 1 024 068 Line scanner with oscillating mirror Side Yes
Table 3-1: CLV variants
