10.18 Bar code example
Fig. 10-40: Scannable bar codes with various module widths (print ratio 2:1)
9876543210
CLV480
2/5 Interleaved
Code 39
Module width
0.35 mm (13.8 mil)
Module width
0.5 mm (19.7 mil)
Module width
1.0 mm (39.4 mil)
A1234A
Codabar
!"#
