Operating Instructions Chapter 6

CLV 480 Bar Code Scanner

Operation

6 Operation

6.1 Overview of steps for starting up the CLV

• Start up the CLV with the factory default settings (quick start).

With this configuration, the CLV can be operated without being connected to a PC.

• Connect the PC (see Chapter 5.5.5 Connecting the CAN interface, Page 5-16) and in-

stall the "CLV-Setup" program (see Chapter 10.6 Installing and operating the "CLV-Set-

up" program, Page 10-29).

• Configure (parameterize) the CLV for the application.

6.2 Default settings

Table 6-1, Page 6-2 and Table 6-2 contain an overview of the factory default settings for

the CLV. The default parameters are such that the CLV can be put into operation either

straight away or following a few minor adjustments. A PC does not need to be connected to

start up the CLV with the default settings.

The default settings are stored permanently both in the ROM of the CLV and in the CLV-

Setup database. They can be loaded to the RAM of the CLV at any time and displayed in the

tabs of the "CLV-Setup" program.

Displaying and printing out a complete set of default settings in CLV-Setup:

1. To save the current settings in the parameter set:

Choose FILE and SAVE AS, and enter a file name in the dialog box that appears.

CLV-Setup saves the current settings in a configuration file with the extension "*.scl".

2. Click in the toolbar.

CLV-Setup loads the default settings from its internal database and displays them in the

tabs.

3. Click in the toolbar.

The PRINT FILE dialog box is displayed.

4. If desired, a comment can be entered in the input field for the header of the printout.

Confirm the entry with OK. The PRINT dialog box for configuring the printer then is

displayed.

5. Make the appropriate entries in the dialog box and confirm these with OK.

CLV-Setup prints out the complete set of default settings in the form of a table. The header

contains the company and user names that were entered during the CLV-Setup installation

routine.
