Chapter 5 Operating Instructions
CLV 480 Bar Code Scanner
5-22 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Electrical installation
For connecting the host interface via the AMV/S 60 Connection Module, see the Operating
Instructions "AMV/S 60 Connection Module" (no. 8 008 296).
Tip
The output function, pulse duration (timer), and polarity of the signals can be changed on
the D
EVICE CONFIGURATION tab in the "CLV-Setup" program.
¾ Click the RESULT OUTPUTS PARAMETERS button.
Enter the values in the tab displayed. Download all changes to CLV!
Recommendation ¾ To check the switching functions using a high-impedance digital voltmeter, connect a
load to the outputs to prevent incorrect voltage values/switching statuses from being
displayed.
