Operating Instructions Chapter 6
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 6-27
Operation
Fig. 6-6: Reading result of the terminal interface: structure for Good Read
Good Read:
TT=_ _380 ms MG=_52 % n=_1 AK=1
LS= _ _ _0 FL= _ _ _0 SB= _ _0 MB= _ 11 RM= _ _ _0
0123412345
C39 100% ST=0 CL=10 CP=_52 CD=_500 CS= 300 CA=300 CK=999 DI=F
PO=+_14 OW=+_ _0 FC=_500 CX=_913 CY=_612 CZ=1408 ON= _ _ _0
MW= _ _40 VL= _ _ _0 CI= _ _0
With:
1st. line: TT = Duration of the reading interval (ms)
MG = Temporal mean value of the identification quality (%)
n = Number of detected bar codes
AK = No. of the used distance configuration
2nd. line: LS = Special parameter for SICK-Service
FL = Special parameter for SICK-Service
SB = Special parameter for SICK-Service
MB = Special parameter for SICK-Service
RM = Special parameter for SICK-Service
3rd. line: 0123412345 = Data contents of the bar code
4th line: C39 = ID: Code type Code 39 along
100% = Identification quality (%)
ST = Read status (ST = 0: Good Read)
CL = Code length (number of characters)
CP = Code position
CD = Code distance (radial measured)(mm)
CS = Code reliability
CA = Scan effort
CK = Code continuity
DI = Decoding direction
(F = in scanning direction, R = against scanning direction)
5th line: PO = Exact code position (3-digit for tracking) (scale factor: 0.1°)
OW = Exact oscillating angle (3-digit for tracking) (scale factor: 0.1°)
FC = Current focus position (4-digit for tracking) (mm)
CX = X-coordinate of bar code (for OTS in transport direction)
CY = Y-coordinate of bar code (for OTS across to transport
direction)
CZ = Z-coordinate of bar code (for OTS from above directly)
6th line: MW = Modul width
VL = Velocity
CI = Special parameter for SICK-Service
Fig. 6-7: Reading result of the terminal interface: structure for No Read
No Read:
TT=_ _ 360 ms MG=_51 % n=_0 AK=1
LS= _ _ _0 FL= _ _ _0 SB= _ _0 MB= _ _1 RM= _ _ _0
no code!
With:
1st. line : TT = Duration of the reading interval (ms)
MG = Temporal mean value of the identification quality (%)
n = Number of codes detected
AK = No. of the distance configuration used
2nd. line: LS = Special parameter for SICK-Service
FL = Special parameter for SICK-Service
SB = Special parameter for SICK-Service
MB = Special parameter for SICK-Service
RM = Special parameter for SICK-Service
3rd. line: no code! = No. bar codes found!
