Chapter 9 Operating Instructions
CLV 480 Bar Code Scanner
9-2 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Technical data
9.2 Data sheet CLV 480-1010 bar code scanner
Technical data as CLV 480-0010 with the following exceptions:
9.3 Data sheet CLV 480-0011 bar code scanner
Technical data as CLV 480-0010 with the following exceptions:
Enclosure rating/protection class IP 65
3)
(to DIN 40 050)/class 3(to VDE 0106/IEC 1010-1)
EMC/vibration/shock tested to EN 61000-6-2, 61000-6-3/to EN 60068-2-6/to EN 60068-2-27
Weight approx. 1.5 kg (approx. 3.3 lb)
Ambient operating/storage temperature 0 to +40 °C/–20 to +70 °C (+32 to +104 °F/–4 to +158 °F)
Max. rel. humidity 90 %, non condensing
Color SICK blue (RAL 5012)
3) With plug cover or plug cover with parameter memory
Type CLV 480-0010
Table 9-1: Technical specifications of the CLV 480-0010 (contd.)
Type CLV 480-1010
Design line scanner with oscillating mirror
Reading window side
Angle of emergence 105° (center position CW = 50)
Trigger source for focus control also: oscillating mirror reversal points
Useful aperture angle max. 50°
Oscillating mirror functions
permanent (variable position)/oscillating (amplitude per DC variable or fixed)/One-Shot
1)
Oscillating frequency 0.2 to 4 Hz
Max. angle of deflection
max. ±20° (±40 CW), (set with software)
Reading ranges see Page 10-13
Deflection ranges see Page 10-21
Operating voltage/power consumption 18 to 30 V DC pursuant to ICE 364-4-41/ typically 13 W, max 18 W
Weight approx. 2.2 kg (approx. 4.84 lb)
1)
One-Shot: one-off oscillating movement per reading pulse (start position and velocity can be selected for forward and return phase)
Table 9-2: Technical specifications of the CLV 480-1010
Type CLV 480-0011
Design line scanner with heater
Switching on function/temperature graph see Chapter 10.4 Optional heating, Page 10-26
Power-on delay 35 to 40 min (at 24 V DC and min. ambient operating temperature –35 °C (–31°F))
Operating voltage 24 V DC +20 % /–10 % pursuant to ICE 364-4-41
Power consumption typically 75 W, max 90 W
Required cross-section
min. 0.5 mm
2
(20 AWG), for power supply
Weight approx. 1.5 kg (approx. 3.3 lb)
Ambient operating/storage temperature –35 to +35 °C/–20 to +70 °C (–31 to +95 °F/–4 to +158 °F)
Table 9-3: Technical specifications of the CLV 480-0011
