SICK CLV 480 - Table 6-5: Guide: Parameterizing Oscillating Mirror Functions

Chapter 6 Operating Instructions
CLV 480 Bar Code Scanner
6-10 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Operation
• Scanning frequency Ö READING CONFIGURATION tab Ö READING PARAMETERS section
• Blank zone Ö READING CONFIGURATION tab Ö READING PARAMETERS section Ö
(Start/stop ratio)
• Poor quality bar code print (e.g. bad contrast) or scattered print Ö READING CONFIGU-
RATION tab Ö CODE LABEL CHARACTERISTICS section Ö Code label quality and Background
noise
• Reading with high tilt Ö READING CONFIGURATION tab Ö CODE LABEL CHARACTERISTICS section
Ö Relative modul width
• Reading bar codes with small height (bar length) by SMART decoder Ö CODE
CONFIGURATION tab Ö DECODER section/SMART PARAMETERS button
c
b) Parameterizing optical read properties of the scanner
c) Optional: Parameterizing oscillating mirror functions
Action Settings in CLV-Setup
1. Choose "Oscillating with fixed amplitude"
mode
(identical amplitude for all distance
configurations)
– or –
Ö OSCILLATING MIRROR tab
Ö OSCILLATING MIRROR section
– Oscillating with fixed amplitude
Ö OSCILLATING section
– Frequency
2. Choose "Oscillating with variable amplitude"
mode
(amplitude can be chosen for each distance
configuration)
– or –
Ö OSCILLATING MIRROR tab
Ö OSCILLATING MIRROR section
– Oscillating with variable amplitude
Ö OSCILLATING section
– Frequency
Ö READING CONFIGURATION tab
Ö DISTANCE CONFIGURATION button
– Oscillating Mirror Amplitude (CW value)
3. Choose "Fixed Position" mode
– or –
Ö OSCILLATING MIRROR tab
Ö OSCILLATING MIRROR section
– Fixed Position
Ö FIXED POSITION section
– Stationary Position (CW)
4. Choose "One-Shot" mode Ö OSCILLATING MIRROR tab
Ö OSCILLATING MIRROR section
– One-Shot
Ö ONE-SHOT section
Ö PHASE 1
– Mirror Speed
– Start Position
– Distance Configuration (no.)
Ö PHASE 2
– Mirror Speed
– Start Position
– DistanceConfiguration (no.)
5. With One-Shot: choose trigger source Ö OSCILLATING MIRROR tab
Ö ONE-SHOT section
Ö TRIGGER MODE
– Reading Trigger Pulse or
– Switching input or
– Serial Interface
Table 6-5: Guide: Parameterizing oscillating mirror functions
