Operating Instructions Chapter 4
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 4-1
Installation
4 Installation
4.1 Installation sequence
• Change the language version of the laser warning label (if necessary)
• Select the mounting location for the CLV
• Align the CLV with the bar code and mount the CLV
• Mount the AMV/S 60 Connection Module
• Connect the CLV to the AMV/S 60 Connection Module
• Adjust the CLV so that it is in line with the bar code
• Mount the reading pulse sensor for external triggering the reading pulse
• Option with event-controlled dynamic focus control:
mount the sensors for detecting the object distance
Note Don’t open the device. The producer warranty will be forfeited if the device is opened.
4.2 Preparations
4.2.1 Required components
• CLV Bar Code Scanner
4.2.2 Required accessories
• SICK mounting bracket for the CLV: depending on the order,
angle bracket no. 2 013 824, articulated bracket no. 2 018 435, or quick-clamping
device no. 2 016 110 with securing material for the CLV
– or –
Alternatively, if the bracket is supplied by the user
– Stable mounting device that allows the alignment of the CLV to be varied in the x and
y axes. The weight of the CLV (line scanner) is 1.5 kg (3.3 lb) and 2.2 kg (4.84 lb) as
a line scanner with oscillating mirror.
– 2 screws M6 for the CLV. The screw length depends on the wall thickness of the brak-
ket used. Depth of engagement in CLV max. 7 mm (0.28 in) from housing surface.
• AMV/S 60 Connection Module (not included in the scope of supply of the CLV)
• Reading pulse sensor(s) for external reading pulse triggering, e. g. photoelectric reflex
switch(es)/photoelectric proximity switch(es) (not included in the scope of supply)
• Option with event-controlled dynamic focus control: sensors for detecting the object
distance, e. g. photoelectric reflex switches/photoelectric proximity switches (not
included in the scope of supply of the CLV)
• Optionally for separation of bar codes with the same name (same code type, identical
data content): an incremental encoder (not included in the scope of supply of the CLV)
4.2.3 Required auxiliary parts
• 2 screws M6 for securing the SICK mounting bracket to the base. The screw length
depends on the wall thickness of the base.
• Set of laser warning labels (if necessary)
• Tool
• Measuring tape (up to 3 m (118.2 in))
• Protractor
