SICK CLV 480 - Installing and operating the CLV-Setup program

Operating Instructions Chapter 10
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 10-29
Appendix
10.6 Installing and operating the "CLV-Setup" program
The scope of delivery of the CLV includes a CD-ROM ("Manuals & Software") containing the
"CLV-Setup" program. The software can be installed on a PC with the following minimum
configuration: 80486 processor, 66 MHz, and 16 MB RAM, CD drive, serial interface and
mouse (recommended) as well as an operating system Windows 95
TM
/98
TM
, Windows NT
TM
,
Windows
2000
TM
or Windows XP
TM
.
Approximately 25 MB of hard disk space is required to install CLV-Setup (V 4.10) and CLV
Assistant, approximately 20 MB to install CLV-Setup Help (V 4.10).
Note For the lastest version of the software, see www.sick.com.
10.6.1 Preparations
1. Make sure you have the CD-ROM ("Manuals & Software") at hand.
2. Connect the CLV to the AMV/S 60 Connection Module (see Chapter 5.5.3 Connecting
the supply voltage, Page 5-14).
3. Connect the PC to the terminal interface on the CLV using a 3-core RS 232 data cable
(null modem cable) (AMV/S 60: connect the PC to the internal 9-pin "Service" plug).
See Chapter 5.5.5 Connecting the CAN interface, Page 5-16.
4. Switch on the power supply to the AMV/S 60.
Once the CLV has started, the "Device Ready" LED lights up.
5. Switch on the PC and start Windows.
10.6.2 Installing the software
The "CLV-Setup" installation program creates a directory "CLV", a series of subdirectories,
and the necessary links. A deinstaller is also installed automatically so that you can remove
the program from the PC at any time. As of version V
2.6, CLV-Setup will only be available
and further developed as a 32-bit application.
Note The following instructions describe how to install the software on Windows XP
TM
. These in-
structions may differ depending on the operating system you are using (for example, admin-
istrator rights are required to install the software on Windows XP
TM
).
Initial installation
User software CLV-Setup:
1. Shut down all the applications running in Windows.
2. Insert the CD-ROM into the CD-ROM drive.
3. If the auto run function is enabled, the start page (table of contents) of the CD-ROM is
automatically displayed in the your browser.
4. Select the SOFTWARE folder on top left.
5. Select CLV, ICR, OPS SETUP SOFTWARE in the listing.
A table with CLV-Setup information is displayed.
6. Select DOWNLOAD under SOFTWARE FILE.
