Operating Instructions Chapter 5
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 5-11
Electrical installation
Connection cable no. 2 020 264 ("I/0" connection)
15-pin D Sub HD plug and open cable end
b) Connecting the CLV with external parameter memory no. 2 020 981
CLV without heater:
¾ Cover the "Host/Term" and "I/O" connections on the CLV with the connector cover (pa-
rameter memory) no. 2 020 981. Connect the free cable ends accordingly. The wire
color assignments are shown in
Table 5-12 and Table 5-13.
CLV with heater:
Available on request.
Pin Signal Wire color
1
1)
V
S
Red
2 IN 1 White
3 Sensor Brown
4 Result 1 Violet
5 GND Blue
6 IN 0 Green
7 IN 2 Yellow
8 Result 2 Grey
9 INGND Black
10 Result 3 Grey-pink
11 IN 3 Red-blue
12 IN 4 White-green
13 I2C SDA Brown-green
14 I2C SCL White-yellow
15 Result 4 Yellow-brown
– Shield Orange
1) Pin 1 is jumpered with Pin 1 of the "Host/Term" connection in the CLV
Table 5-11: Wire color assignment of the cable no. 2 020 264
