SICK CLV 480 - Reading Performance Data of Line Scanner; Fig. 10-1: CLV 480-0010-0011 (Line Scanner): Reading Field Height as a Function of the Reading Distance and Resolution

Operating Instructions Chapter 10
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 10-3
Appendix
10.2.3 Reading performance data of line scanner
Fig. 10-1: CLV 480-0010/-0011 (line scanner): Reading field height as a function of the reading distance and resolution
Reading conditions: see Table 10-1, Page 10-1
Line scanner (front reading window): CLV 480-0010/-0011
Reading field height
Reading distance
Resolution:
All dimensions in mm (in)
