Chapter 6 Operating Instructions
CLV 480 Bar Code Scanner
6-14 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Operation
The selected reading mode depends on the number of objects that are simultanously in the
reading field of the CLV during each reading interval. This is independent of the number of
bar codes on the actual object.
Table 6-6 shows an overview of the configurations and ap-
plications.
A. CLV in stand-alone configuration
A1. Start/Stop mode
• One object in the reading field per reading interval, reading on one side
Possible reading triggers:
• One external sensor (e. g. photoelectric reflex switch)
• Two external sensors
• Command strings
• Free-running mode
Further preparations:
¾ Configuring distance configurations:
see Chapter a) Parameterizing focus position switchover, Page 6-9
¾ Configuring oscillating mirror (optional):
see Chapter c) Optional: Parameterizing oscillating mirror functions, Page 6-10
¾ Configuring no. of bar codes to be read:
see Chapter f) Parameterizing the evaluation characteristics, Page 6-23
Note The size of the reading field is determined by the distance between the start and stop sen-
sors in conveying direction (see Fig. 3-4, Page 3-8).
d) Parameterizing the reading trigger
Configuration Application See page
A. Stand-alone Start/stop mode
• One object in reading field per reading interval, reading one side
6-14
B. Used in Omni Portal System
(arrangement with OTS 400 and other
CLVs)
Start/stop mode
• One object in reading field per reading interval, CLV involved in read-
ing one side or more sides, master/slave arrangement with OTC 400
controller
Tracking mode (controlled by increment)
• Max. 20 objects in reading field per reading interval, CLV involved in
reading one or more sides, object tracking by OTC 400 controller
6-18
6-20
Table 6-6: Overview: CLV applications in stand-alone configuration or in arrangement with OTS 400
