SICK CLV 480 User Manual

Operating Instructions Chapter 6
CLV 480 Bar Code Scanner
8 010 080/O824/10-02-2005 © SICK AG · Division Auto Ident · Germany · All rights reserved 6-21
Operation
Parameterizing reading trigger in the CLV:
Parameterizing tracking mode in the CLV:
Coose fixed focus and set up
one distance configuration
Ö READING CONFIGURATION tab
Ö FOCUS CONTROL section
– Static (No Trigger)
Ö DISTANCE CONFIGURATION button
Ö DISTANCE CONFIGURATION tab
– Focus Position
– Minimum Code Position CP
– Maximum Code Position CP
Oscillating mirror:
– additional: Oscillating mirror amplitude CW
Ö ASSIGNMENT TABLE tab
– Index
– No. of valid configurations: 1
Action Settings in CLV-Setup
Choose reading trigger Ö DEVICE CONFIGURATION tab
Ö READING TRIGGER SOURCE section
– OTS Trigger
Table 6-13: Guide: Parameterizing reading trigger mode in the CLV for master/slave arrangement
with OTC 400
Action Settings in CLV-Setup
1. Define position of CLV
referred to conveyor belt
Ö DEVICE CONFIGURATION tab
Ö SCANNER POSITION PARAMETERS button
Ö ANGLES section
– alpha, beta and gamma
Ö COORDINATS section
– x-, y- and z-coordinate
2. Parameterize scale factor
for increment pulse
Ö DEVICE CONFIGURATION tab
Ö DISTANCE PER ENCODER PULSE section
– Value
(in agreement with increment sensor and OTC 400)
3. Define release points Ö DEVICE CONFIGURATION tab
Ö TRACKING PARAMETERS button
Ö RELEASE POINTS section
– Focus release point: value
– Object release point: value
4. Define label assignment
tolerance for object gaps
Ö DEVICE CONFIGURATION tab
Ö TRACKING PARAMETERS button
Ö LABEL ASSIGNMENT TOLERANCE section
– Automatic or
– Fixed Tolerance: value
Table 6-14: Guide: Parameterizing tracking mode in the CLV for Object Tracking mode with OTC 400
Action Settings in CLV-Setup
Table 6-12: Guide: Parameterizing focus control in the CLV for master/slave arrangement with
OTC 400 (contd.)
