Chapter 6 Operating Instructions
CLV 480 Bar Code Scanner
6-8 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Operation
Data Strings
This tab and further dialog boxes are used to set the following:
• Data output format of the host interface (telegram format)
• Constants and reading diagnosis data in the "Header", "Code Info/Separator", "Splitter"
and "Terminator" blocks
• Arrangement of the "Code info/separator" blocks in the data string
• Output format for no reads and contents of the error string
• Test string function
• Output sequence and sort criteria for reading more than one bar code per reading pulse
• Format mask and its structure
• Output format of an external data string forwarded as reading result
Auxiliary Interface
This tab and further dialog boxes are used to change the following:
• Operating mode of the terminal interface
CAN Interface
This tab and the further dialog windows are used to change the following:
• CAN interface operating mode
• Data transmission rate
• Type of logical data connection of the connected CLV
• Usage of the switch inputs/outputs of the CLV as CANopen Digital I/O
Oscillating Mirror
This tab is used to set the following:
• Operating mode of the oscillating mirror
• Oscillating frequency
• Angle of deflection (oscillating amplitude)
• Start of oscillating mode
• Trigger source for One-Shot
Extras
This tab is used to edit parameters that were not recognized by CLV-Setup after an upload.
Note CLV-Setup Online Help contains a detailed description of the functions of the parameters and
their valid entries (see
Chapter 10.6.8 CLV-Setup Help, Page 10-36 for calling up Help).
