Chapter 6 Operating Instructions
CLV 480 Bar Code Scanner
6-24 © SICK AG · Division Auto Ident · Germany · All rights reserved 8 010 080/O824/10-02-2005
Operation
Result status of switching outputs:
• Define function of result status output of "Result 1" to "Result 4" ("Read Result" LED:
Result 2) switching outputs Ö D
EVICE CONFIGURATION tab Ö RESULT OUTPUT PARAMETERS
button
Main Data Interface general:
• Destination of result data strings Ö HOST INTERFACE tab Ö DESTINATION OF RESULT DATA
STRINGS section
• Filter reading result Ö DEVICE CONFIGURATION tab Ö ODETTE FILTER section
• Sort reading result Ö DATA STRINGS tab Ö OUTPUT SEQUENCE SORT section
• Mask reading result Ö DATA STRINGS tab Ö FORMAT MASK section
Host Interface:
• Arrangement in data network Ö DEVICE CONFIGURATION tab Ö SCANNER ARRANGEMENT
section
• Physical interface Ö HOST INTERFACE tab Ö DATA FORMAT section
• Communication parameters Ö HOST INTERFACE tab Ö DATA FORMAT section
• Protocol Ö HOST INTERFACE tab Ö INTERFACE PROTOCOL section
Function of the CAN interface (alternative):
See the Operating Instructions ”Application of the CAN interface” (no. 8 009 180)
Data output string of host interface:
• Choose contents of "Header", "Code Info/Separator", "Splitter" and "Terminator"
blocks Ö D
ATA STRINGS tab Ö OUTPUT FORMAT section
• Position of "Code Info/Separator" blocks in data output string Ö DATA STRINGS tab
Ö POSITION OF CODE INFO/SEPARATOR section
• Set wrong read format Ö DATA STRINGS tab Ö Wrong read format, number of characters
and Error String
• If necessary, parameterize/activate test string Ö DATA STRINGS tab Ö TEST STRING
section
• Parameterize special functions Ö DATA STRINGS tab Ö SPECIALS button
• Output external data string as reading result Ö DATA STRINGS tab Ö EXTERNAL DATA
S
TRING PARAMETERS button
• AUXILIARY INTERFACE tab
• DEVICE CONFIGURATION tab Ö START WITH ...
g) Parameterizing the output characteristics
h) Parameterizing the terminal interface (auxiliary interface)
i) Defining the start option for accessing the parameter set
