SICK microScan3 Core I/O

Display Device or configura‐
t
ion
Meaning
Configuration with
r
estart interlock
Reset button pressed Safety output in the OFF
state.
Configuration with
r
estart interlock
Reset button pressed Safety output in the ON
state.
Configuration with
aut
omated restart
after a time
Protective field is clear, configured time to
restart expires.
Configuration with at
le
ast one warning field
Warning field interrupted (left column: num‐
ber of interrupted warning fields, right col‐
umn: number of warning fields in the current
monitoring case).
Display flashes
All devices and config‐
ur
ations
Fault. All safety outputs in the OFF state.
Additional information: see "Fault display",
page 134.
Display flashes
All devices and config‐
urations
Contamination warning. Check the optics cover
for damage. Clean the optics cover.
Display flashes
All devices and config‐
ur
ations
Contamination error. All safety outputs in the
OFF state. Check the optics cover for damage.
Clean the optics cover.
Display flashes
All devices and config‐
ur
ations
Dazzle warning. Check whether the safety
laser scanner is being dazzled by an external
light source in the scan plane, e.g., sun, halo‐
gen light, infrared light source, stroboscope.
Remove or cover the light source.
Display flashes
All devices and config‐
ur
ations
Dazzle error. All safety outputs in the OFF
state. Check whether the safety laser scanner
is being dazzled by an external light source
in the scan plane, e.g., sun, halogen light,
infrared light source, stroboscope. Remove or
cover the light source.
Display flashes
Configuration with
e
xternal device moni‐
toring (EDM)
Fault in the external device monitoring (EDM).
OSSD pair in OFF state.
TROUBLESHOOTING 12
