Important information
DANGER
D
anger of using data output for safety function
Data output may only be used for general monitoring and control tasks.
b
Do not use data output for safety-related applications.
Send Mode
•
D
eactivated: No data output
•
On request: Data is output when there is an explicit request from a host computer
via TCP/IP using CoLa2
•
On request and also continuously to a target computer (router settings made via “Network
settings”):: Data is output continuously via UDP to a defined target address and
also when there is an explicit request from a host computer via TCP/IP using
CoLa2
Selection data content
•
Bloc
k "Device Status": Information on the status of the safety laser scanner (e.g.,
cut-off paths, errors)
•
Block "Configuration of Data Output": Information on the actual angle range used (due
to technical conditions, data may be output from a slightly larger angle range than
the set angle range)
•
Block "Measurement Data" *: Distance data with reflector detection and RSSI
•
Block "Object detection" *: Data on the beams in the fields of the active monitoring
case in which an object was detected
•
Block "Application Data": State of the inputs and outputs used in the monitoring
case table
•
Block "Local I/Os": State of the local inputs and outputs
Angular range
Y
ou define in which range measurement data and data on detections in fields are
output.
Complementary information
F
or additional information on data output, see the technical information “microScan3:
outdoorScan3: Data output via UDP and TCP/IP” (part number 8022706).
7.16 Transfer
Transferring configuration
DANGER
H
azard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of
non-observance.
When transferring the configuration, the protective device’s existing configuration may
be overwritten.
b
Check the configuration carefully before transfer.
b
Make sure that the desired device is connected during transfer.
At first, the configuration only exists as a project, namely as a configuration file. The
conf
iguration must be transmitted to the device.
CONFIGURATION 7
8021219/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 – PROFINET
125
Subject to change without notice
